12. EVENT LOG
The PI-8 control panel has a 19 event memory, these events are stored in non volatile
memory and can not be erased, nor will they be lost in the event of a complete power loss
to the panel.
To display the alarm memory proceed as follows:
1. Hold down the 0 key for three seconds.
2. The following combinations of indicators will show the type of event which has
occurred:
EVENT TABLE
KEYPAD LEDS STATUS EVENT TYPE
READY LED on Circuits bypassed during a set cycle
READY and TAMPER LEDs on Circuits alarmed during a set cycle
READY LED flashing Circuits bypassed during a part set cycle
READY and TAMPER LEDs flashing Circuits alarmed during a part set cycle
POWER LED on Mains failure
POWER LED flashing Low battery
TAMPER LED on Tamper
TAMPER LED flashing Panic
POWER and TAMPER LEDs flashing Duress
In addition to the above, any circuit LEDs show which circuits were bypassed/alarmed.
3. Press the * key to scroll back through the events.
4. Press the # key to exit this mode. If the # key is not pressed and there are no further
key strokes this mode will timeout in 15 seconds.
Example
1. Ensure that the panel is not set.
2. Hold down the 0 key for three seconds.
3. e.g. The READY, TAMPER, CIRCUIT 1 and CIRCUIT 2 LEDs were on.
This combination of LEDs means that circuits had alarmed during a set cycle
(READY and TAMPER LEDs), while the circuit 1 and circuit 2 LEDs show that
circuits 1 and 2 were the circuit which alarmed.
4. Press the * key to advance to the next entry in the event log.
5. e.g. The POWER LED was flashing.
This would indicate that prior to the event indicated in point 3 above a low
battery condition was detected.
6. Repeat step 4 until all events have been viewed.
7. To exit this mode press the # key.
