PX Control Panel User Manual – Issue C
- 38 -
Schedule (PX18 & 34)
Code-25
Feature PX18 PX34
Max. Schedules 4 8
A schedule can be used to:
1. Auto set and unset parts of the system
2. Control outputs
3. Enable/disable keypads
4. Enable/disable user access
To program a schedule, select the schedule option from the main menu followed by the schedule
number. The schedule menu will then be displayed.
Schedule Options
Schedule-x x=Schedule number
Start Time-00:00 HH:MM
Stop Time-00:00 HH:MM
Mon-Off On/Off
Tue-Off On/Off
. . .
Sun-Off On/Off
Holiday-Off On/Off
Schedule Menu
Start Time
HH:MM
To disable a schedule the start and stop times should be set to 00:00.
Schedule Menu
Stop Time
HH:MM
To disable a schedule the start and stop times should be set to 00:00.
Schedule Menu
Mon-Sun
On/Off
Each schedule can be configured for any combination of days, if the start or stop times are non zero.
The programmed schedule function will not operate on days that are programmed as off.
Schedule Menu
Holiday
On/Off
If the holiday option is on, then the schedule operation will be suspended on dates that are programmed
as holidays.
Intelligent Security & Fire Ltd
