PX Control Panel User Manual – Issue C
- 6 -
User, Set group and Circuit Identification
Each user, set group, and circuit can be programmed with a text description. An authorised user can
change a user text descriptor.
User Codes
Each user of the system is identified by a unique code. This code can be a PIN code, an electronic key
or proximity token. An electronic key can only be used on a keypad variant with an electronic key
interface. A proximity token can only be used on a keypad variant with a proximity interface.
Throughout this manual user codes are only referred to as codes.
Operator Controls and Displays
System Keypads
2 x 16 character
LCD backlit display
Mains indicator
Optional electronic
key socket
The operator keypad unit incorporates a backlit liquid crystal display (LCD) comprising 2 lines of 16
characters, and a backlit keypad to gain access to the system and to perform all authorised user
functions. Keypads may be fitted with an electronic key socket or an internal proximity reader. The
keypad incorporates a mains power indicator. This indicator will flash if the system is operating on
standby battery power.
12:00 Mon 20 Dec
