PX Control Panel User Manual – Issue C
- 39 -
Schedule (PX80 & 500)
Code-25
Feature PX80 PX500
Max. Schedules 16 32
A schedule can be used to:
1. Auto set and unset parts of the system
2. Control outputs
3. Enable/disable keypads
4. Enable/disable user access
To program a schedule, select the schedule option from the main menu followed by the schedule
number. The day menu will then be displayed.
Schedule Options
1=Mon
2=Tue
3=Wed
4=Thu
5=Fri
6=Sat
7=Sun
8=Hol
Select the day or holiday (Hol) to program the schedule times:
Schedule Options
Schedule-nn Day nn=Schedule number, Day= selected day or holiday
Start 1-00:00 HH:MM
Stop 1-00:00 HH:MM
Start 2-00:00 HH:MM
Stop 2-00:00 HH:MM
Two sets of times may be programmed for each schedule day. This allows, for example, 2 access
periods to be configured for a user or 2 auto set/unset times.
Set Group
Code-26
A descriptor of up to 10 characters may be entered for each set group. Refer to the user name section
for details of how to change a descriptor.
Intelligent Security & Fire Ltd
