GW Instek GPT-12004 Quick Start Guide

INTRODUCTION
11
Rear Panel Overview
GPT-12001/12002/12003/12004
1
3
7 8 9 0 A
B
C
D
2
4
5
6
E
Item
Description
1
HIGH VOLTAGE Output Terminal
2
HIGH VOLTAGE Indicator
3
SENSE H & Output Terminal
4
SENSE L & RETURN Terminal
5
SOURCE H (GPT-12004 only)
6
SOURCE L (GPT-12004 only)
7
Fan
8
RS-232 Port
9
USB B-Type Interface Port
0
Scan Port
A
Signal I/O Port
B
GPIB Port (Optional)
C
GND
D
AC Mains Input (Power Cord Socket)
E
HIGH VOLTAGE pilot lamp

GW Instek GPT-12004 Specifications

General

Brand	GW Instek
Model	GPT-12004
Category	Measuring Instruments
Language	English
