GW Instek GPT-12004 Quick Start Guide

OPERATION
23
PASS Status
Background
When a MANU test result is within the range of
HI and LOW sets, the PASS status is shown on
display. For AUTO test, the PASS status only
shows when all the affiliated test steps are passed.
PASS status in
MANU test
PASS status in
AUTO test
FAIL Status
Background
When a MANU test result is beyond the range
of HI and LOW sets, the FAIL status is shown
on display. For AUTO test, the FAIL status is
shown when any of the test steps fails, even
only one of them.
FAIL status in
MANU test
