GW Instek GPT-12004 Quick Start Guide

GPT-10000 Series Quick Guide
22
READY Status
Background
When the tester is in READY status of MANU
or AUTO test, it is ready to begin testing.
Pressing the START button will begin testing
and put the tester into TEST status. Pressing the
AUTO key will change from MANU – READY
status to AUTO – READY status and vice versa.
READY status
in MANU test
READY status
in AUTO test
TEST Status
Background
TEST status is active when a MANU test or
AUTO test is running. Pressing STOP will
cancel the MANU test or the remaining steps in
an AUTO test instantly. The TEST status in
AUTO test is identical with that of MANU test.
TEST status in
MANU test
