Appendix A Chassis views and technical
specifications
Chassis views
S1205
Figure 16 S1205 front panel
(1) Power LED (2) Copper port LEDs
Figure 17 S1205 rear panel
(1) Security slot (2) 10/100/1000BASE-T copper ports
(3) DC Power receptacle
S1205-PWR
Figure 18 S1205-PWR front panel
(1) Power LED (2) Copper port LEDs
(3) PoE status LEDs (4) PoE-MAX LED
