H3C S1200 Series User Manual

15
Figure 27 S1224 rear panel
(1) Grounding screw (2) AC power receptacle
S1224F
Figure 28 S1224F front panel
(1) 10/100/1000BASE-T copper ports (2) 100/1000BASE-X SFP fiber ports
(3) Copper port LEDs (4) Power LED
(5) Fiber port LEDs
Figure 29 S1224F rear panel
(1) Grounding screw (2) AC power receptacle
S1224P-X
Figure 30 S1224P-X front panel
(1) 10/100/1000BASE-T copper ports (2) 1000BASE-X SFP/10GBASE-SR/LR SFP+ ports
(3) Copper port LEDs (4) Power LED
(5) Fiber port LEDs
1 2 3 4 5
