H3C S1200 Series - S1208; S1208-Pwr

13
Figure 19 S1205-PWR rear panel
(1) Security slot (2) 10/100/1000BASE-T copper ports
(3) DC power receptacle (4) Grounding screw
S1208
Figure 20 S1208 front panel
(1) Power LED (2) Copper port LEDs
Figure 21 S1208 rear panel
(1) Security slot (2) 10/100/1000BASE-T copper ports
(3) DC power receptacle
S1208-PWR
Figure 22 S1208-PWR front panel
(1) Power LED (2) Copper port LEDs
(3) PoE status LEDs (4) PoE-MAX LED
