26
Figure 45 Storage controller configuration screen
2. On the screen as shown in Figure 46, select a target RAID level and press Enter.
Figure 46 Logical Device Configuration screen
3. On the screen as shown in Figure 47, navigate to a drive, and then press the space bar to
select the drive. [Yes] indicates that the drive has been selected for the RAID array. Then,
press C.
