14
Figure 19 Selecting a RAID level
5. On the screen as shown in Figure 20, set the Array Label, Stripe Size, Array Size, Array
Size Selection, Read Cache, Write Cache, and Create RAID via parameters, select
SUBMIT, and press Enter to create the array.
Table 4 describes the configuration parameters.
Figure 20 Setting RAID parameters
Table 4 Configuration parameters
Array Label RAID array name. The default is
DefaultValue0
.
Stripe Size Strip size, which determines the data block size of a stripe on each drive.
