H3C UniServer R4900 G3 User Manual

39
3. On the screen as shown in Figure 65, select Controller Mode, and press Enter.
Figure 65 Controller Configuration screen
4. On the screen as shown in Figure 66, select a storage controller operating mode (Table 7
describes the storage controller operating modes), and press Enter.
Figure 66 Selecting a storage controller operating mode
Table 7 Storage controller operating modes
Operating mode
Description
RAID: expose RAW
All RAID functions can be used. Raw physical drives are exposed to
the system.
RAID: hide RAW
All RAID functions can be used. Raw physical drives are not exposed
to the system.
HBA
RAID functions are disabled. Raw physical drives are exposed to the
