440

TECHNICAL REFERENCE

June 1999

96-8000

When a tool change operation is performed, the following sequence of events occurs:

1) Z axis moves up to machine zero,

2) If the spindle is turning, it is commanded to stop; coolant stopped,

3) Spindle oriented to Tool Changer,

4) Turn TSC pump off, (optional)

5) Turn purge on and off (optional)

6) Pre-charge is on (40 taper spindle only),

7) Shuttle moves in to receive tool,

8) Tool unclamps,

9) Z axis moves up,

10) Tool Changer rotates,

11) Z axis moves down,

12) Tool clamps,

13) Pre-charge off (40 taper spindle only),

14) Shuttle moves out.
