Haas VF-6 User Manual

452
TECHNICAL REFERENCE
June 1999
96-8000
P36 115V AC to CB4 (90C)
P37 115V AC spare (870)
P38 Door open (1050)
P39 Tool changer turret motor output (810)
P40 (770A) A/B
P43 Ground fault sense signal input (1060) Axis Brake
P44 5TH axis brake (319)
P45 HTC Shuttle
P46 Chip Conveyor (140)
P47 Skip input signal (1070)
P48 spare 1
P49 spare 2
P50 Spigot Motor (200)
P51 16 PIN Relay drivers 17-24 (530)
P52 spare 1
P53 Spigot Sense (180)
P54 Servo Brake (350)
P55 Red/green lights (280)
P56 Thru spindle coolant pump (940A)
P57 115V spare
P58 115V spare

Haas VF-6 Specifications

General

Machine Type	Vertical Machining Center
Spindle Motor	30 hp
Travels X Axis	64 in (1626 mm)
Travels Y Axis	32 in (813 mm)
Travels Z Axis	30 in (762 mm)
Spindle Speed	8, 100 rpm
Rapid Traverse on X	25.4 m/min
Rapid Traverse on Y	25.4 m/min
Rapid Traverse on Z	25.4 m/min
