466
TECHNICAL REFERENCE
June 1999
96-8000
FUSE NAME TYPE RATING VOLTAGE LOCATION
(amps)
FU1 AGC ½ 250V POWER pcb, upper right
FU2 AGC ½ 250V " "
FU3 AGC ½ 250V " "
(not used)Lamp AGC ½ 250V POWER pcb, lower left
FU1 ABC 5 250V I/O PCB
FU2 ABC 5 250V I/O PCB
FU3 ABC 5 250V I/O PCB
FU4 ABC 5 250V I/O PCB
F1 ABC 15 250V Amplifier (X,Y,Z,A,B)
