Haas VF-6 User Manual

71
INSTALLATION
June 1999
96-8000
3. Attach the lifting chains and hooks to the lifting points, with the rigging beam, spreader bar, and
spacer block in place. Position the spreader bar so the lifting chains do not come into contact
with the waycovers.
Fig. 3-3 VF-6/8 lifting positions.
4. Use the spacer block to keep the chains from damaging the rear conduit lines.
* On machines with eyebolt through holes, reinstall the hole plugs.
5. The following weight specifications are an approximation of weight distribution and chain length
required to lift the machines.
enihcaM)sdnuop(thgieWhtgneLniahC
)nmuloc(
E/O-FV
TXE/EO-FV
1-FV
2-FV
3-FV
4-FV
04/5-FV
05/5-FV
6-FV
7-FV
8-FV
9-FV
01-FV
11-FV
000,7
009,7
001,7
000,8
005,21
003,31
005,41
006,41
000,12
000,32
000,42
000,52
000,82
004,92
-
-
-
-
-
-
-
-
"021
"021
"021
"021
"021
"021

Haas VF-6 Specifications

General

Machine Type	Vertical Machining Center
Spindle Motor	30 hp
Travels X Axis	64 in (1626 mm)
Travels Y Axis	32 in (813 mm)
Travels Z Axis	30 in (762 mm)
Spindle Speed	8, 100 rpm
Rapid Traverse on X	25.4 m/min
Rapid Traverse on Y	25.4 m/min
Rapid Traverse on Z	25.4 m/min
