Hach 2100Q User Instructions

N O T I C E
When using nickel metal hydride (NiMH) batteries, the battery icon will not
indicate a full charge after freshly charged batteries have been inserted (NiMH
batteries are 1.2 V versus 1.5 V for alkaline batteries). Even though the icon does
not indicate complete charge, 2300 mAH NiMH batteries will achieve 90% of
instrument operation lifetime (before recharge) versus new alkaline batteries.
N O T I C E
To avoid potential damage to the meter from battery leakage, remove the meter
batteries prior to extended periods of non-use.
The meter can be powered with AA alkaline or rechargeable NiMH
batteries. To conserve battery life, the meter will power off after
10 minutes of inactivity. The backlight powers off after 30 seconds.
Select a new time in the Power Management menu to change the
power-off default times.
Note: Rechargeable batteries will only be recharged with the USB+Power module.
Refer to the Instrument User Manual for additional information about
battery installation.
Module installation
Refer to the numbered procedure steps for instructions on how to install
the power module, USB module and USB+Power module.
6 English

Hach 2100Q Specifications

General

Range	0 - 1000 NTU
Resolution	0.01 NTU on lowest range
Detector	Silicon photodiode
Stray Light	< 0.02 NTU
Measurement Method	Nephelometry
Power Supply	4 AA alkaline batteries
Operating Temperature	0 to 50 °C
Storage Temperature	-20-60°C
Measurement Modes	Signal Averaging, Rapidly Settling Turbidity
Display	LCD
Accuracy	±2% of reading plus stray light from 0 to 1000 NTU
Light Source	Tungsten filament lamp
