Hach 5500sc SiO2 User Manual

Configure the outputs
4–20 mA module setup
1. Push menu and select SETUP SYSTEM>SETUP OUTPUTS>4–20mA SETUP.
2. Select the OUTPUT.
3. Select an option.
Option Description
ACTIVATION The menu list items change with the selected function. Refer to 4–20 mA activation
options on page 11 for more information.
SELECT SOURCE Select the output. Options: None if the output is not configured, the analyzer name or
calculation if a calculation formula has been configured. Refer to Set up the calculation
on page 10.
SET PARAMETER Select the measurement channel from the list.
SET FUNCTION Select a function. Further options will vary depending on which function is chosen.
LINEAR CONTROL—Signal is linearly dependent on the process value. PID CONTROL
—Signal works as a PID (Proportional, Integral, Derivative) controller. LOGARITHMIC—
Signal is represented logarithmically within the process variable range. BILINEAR—
Signal is represented as two linear segments within the process variable range.
SET TRANSFER If TRANSFER is or will be selected as the ERROR HOLD MODE, select SET
TRANSFER and enter the transfer value. Range: 3.0 to 23.0 mA (default = 4.000). Refer
to Set the error hold mode on page 14.
SET FILTER Enter the filter value. This is a time-average filter value of 0 to 120 seconds (default = 0).
SCALE 0mA/4mA Select the scale (0–20 mA or 4–20 mA).
4–20 mA activation options
1. Push menu and select SETUP SYSTEM>SETUP OUTPUTS>4–20mA SETUP.
2. Select the applicable OUTPUT.
3. Select SET FUNCTION>LINEAR CONTROL and then select the applicable options in the
ACTIVATION menu.
Option Description
SET LOW VALUE Sets the low endpoint of the process variable range.
SET HIGH VALUE Sets the high endpoint (upper value) of the process variable range.
4. Select SET FUNCTION>PID CONTROL and then select the applicable options in the
ACTIVATION menu.
Option Description
SET MODE AUTO—the signal is automatically controlled by the algorithm when the analyzer uses
proportional, integral and derivative inputs.
MANUAL—the signal is controlled by the user. To change the signal manually, change the
% value in MANUAL OUTPUT.
PHASE Selects the signal result when process changes occur.
DIRECT—signal increases as the process increases.
REVERSE—signal increases as the process decreases.
SET SETPOINT Sets the value for a control point in the process.
PROP BAND Sets the value for the difference between the measured signal and the necessary setpoint.
INTEGRAL Sets the period of time from the reagent injection point to the contact with the measuring
device.
English 11

Hach 5500sc SiO2 Specifications

General

Power Requirements	100 - 240 VAC, 50/60 Hz
Resolution	0.001 mg/L
Light Source	LED
Detector	Photodiode
Sample Flow Rate	200 to 500 mL/min
Operating Temperature	5 to 45 °C
Sample Temperature	5 to 45 °C
Outputs	4-20 mA
Enclosure	NEMA 4X/IP66
Method	Heteropoly blue method

Summary

Safety Information

Installation Manual Safety Reference

Reference to installation manual for safety, hazards, and labels.

User Interface and Navigation

Keypad Description

Explanation of the keypad and navigation functions using Figure 1.

Display Description

Explanation of measurement and system status screens using Figures 2 and 3.

PROGNOSYS Indicator Bars

Service Indicator Bar Color Meaning

Defines colors (Green, Yellow, Red) for service task reminders.

Measurement Quality Indicator Bar Color Meaning

Defines colors (Green, Yellow, Red) for analyzer health percentage.

Display Features

Additional Display Formats

Details single/multi-channel display options and graphical display functionality.

Graphical Display Settings

Explains how to set measurement value and date/time range for graphs.

Hardware Component Locations

Power Switch and SD Card Location

Identifies the location of the power switch, SD card slot, and indicator lights via Figure 4.

Status Indicator Light

Status Indicator Definitions

Defines the meaning of Green, Yellow, and Red status indicator lights.

Startup

Reagent Preparation

Safety warning and steps to prepare reagents for the analyzer.

Standard Preparation

Stock Solution and Standards Preparation

Procedures for preparing phosphate stock solution, zero standard, and 3 mg/L standard.

Analyzer Power On

Turn On the Analyzer Steps

Instructions for opening the door, panel, and activating the power switch.

Analyzer Setup

Initial Configuration Steps

Steps for setting up language, date, time, channel, and measurement mode.

Sequencer Configuration

Activate and Sequence Channels

Options to start/stop sources and set measurement order for multi-channel analyzers.

Calibration and Operation

Calibration Recommendation

Manufacturer recommendation for calibration after 1 day of operation for system stabilization.

Operational Safety Warning

Warning about fire and explosion hazard with flammable samples.

Reagents and Standards Setup

Setting and Resetting Levels, Priming

Options to set/reset reagent, standard, and cleaning solution levels, and to prime reagents.

Grab Sample Options

Analyze External Sample or Extract Sample

Options for GRAB SAMPLE IN (external analysis) and GRAB SAMPLE OUT (extract sample).

Grab Sample Procedures

Measure External Sample or Standard

Steps using a funnel to measure grab samples or standards for calibration verification.

Dispense Analyzer Grab Sample

Steps to manually dispense a grab sample from a source for external analysis.

System Setup Configuration

Measurement Modes, Units, and Naming

Settings for measurement mode, interval, units, averaging, and analyzer/channel names.

System Configuration Options

Sample, Date, Display, and Reminders

Settings for sample detection, date/time, display, and disabling reminders.

Device Management and Information

Procedures for managing devices and viewing instrument information.

Calculation and Network Setup

Options for setting up calculations, network, security, air purge, and factory defaults.

Calculation Setup

Set Calculation Variables

Selects sensors referring to variables X and Y for calculation formulas.

Calculation Configuration

Setting Calculation Parameters

Options to set parameters, variables, formulas, display format, units, and measurement names.

Output Configuration

4-20 mA Module Setup

Configuration for 4-20 mA output, including activation, source, function, filter, and scaling.

4-20 mA Activation Options

Specific activation options for 4-20 mA output, such as setting low and high values.

4-20 mA Output Functions

PID, Logarithmic, and Bilinear Control

Configuration options for PID, Logarithmic, and Bilinear control functions of 4-20 mA outputs.

Relay Setup

Relay Activation and Source Selection

Setup for relay activation and selecting the output source.

Relay Setup Options

Function, Transfer, and Fail Safe Settings

Configuration for relay functions like alarm, control, scheduler, and fail-safe modes.

Relay Activation Parameters

Detailed settings for alarm, feeder control, event control, and scheduler relay activation.

Relay Event Control and Scheduling

Event Control and Timer Settings

Settings for event control, deadband, and various timer options for relays.

Scheduler, Warning, and Process Event Relays

Configuration for scheduler, warning level, and process event relay actions.

Error Hold Mode

Output Handling During Communication Loss

Options to hold or transfer outputs when communications are lost.

View Data

Analyzer Data and Measurement Information

Access to analyzer status, measurement data, and event logs.

Analyzer Data Details

Element Definitions

Definitions for elements like cell temperature, reagent levels, and sample pressure.

Measurement Data Details

Measurement Data Elements

Definitions for measurement data like last channel, absorbance, concentration, and reagent delivery times.

View Instrument Information

Analyzer and Module Information

Shows software information, serial numbers for analyzer and connected modules.

LINK2SC Setup

Job Creation and Management

Secure data exchange setup for jobs, including creating, listing, and managing job IDs.

SD Card Usage

Software Upgrade and Log Saving

Options for upgrading software, saving logs, managing configurations, and working with device files.

Firmware Update

Updating Controller, Sensor, or Network Card

Procedure to update firmware using an SD card with an upgrade file.

Calibration

Calibration Options Overview

Menu to view calibration data, start/cancel auto calibration, override, or reset calibration.

Schedule Automatic Calibrations

Automatic Calibration Scheduling

Steps to schedule slope or zero calibration, including time base and interval settings.

Start a Calibration Manually

Manual Calibration Initiation

Procedure to start a manual calibration, including interrupting current measurement.
