10
Installation
Figure 2 CL17 instrument dimensions (1 of 3)
1 Air purge quick connect
.25 O.D. Polyethylene Tubing, (4743800)
4 Power connections
2 Relay / alarm contact connections 5 4 x ¼” recommended mounting bolt
3 Network and 4-20 mA connections
