Hach LPV445.99.02110 Service Manual

Step Description Picture
6 Turn the optical unit and insert an aperture.
7 Insert the interference filter.
Note: Make sure that the wavelength is correct.
Note: Make sure that the wavelength label is readable.
8 Push the LED head in the housing. Bend the pins 90°. Note
the polarity and direction.
Push the housing in the optical unit.
Repairs
40
