Haier HLP21N Installation And User Manual

17
2. Thread the white end of the inlet hose by hand onto the inlet valve on the back of
the washer until rmly hand tightened.
IMPORTANT:
•
Do not connect the gray end of the inlet hose to the washer. You will damage
the threads and it will leak.
•
To avoid damage to the hose couplings, do not over tighten.
Style 1 - Using pliers, tighten the connection an additional two-thirds turn.
Style 2 - Do not use pliers to tighten the connection.
NOTE: To avoid damage to the washer inlet valve, do not use thread seal tape or
sealants on the valve threads.
Style 1 Style 2
a
a
a White End Only
OPTION 1 - FIXED
NOTE: In order for this washer to meet the regulated energy standards, the faucet
supplying the water must be set to cold.
1. Thread the grey end of the inlet hose onto the water faucet by hand until snug.
Then using pliers, tighten an additional two-thirds turn.
IMPORTANT: To avoid damage to the hose coupling, do not overtighten.
NOTE: To avoid damage to the faucet do not use thread seal tape or sealants on
the valve threads.
Cold
a
a Gray End Only
2. Turn on the water faucet and check for leaks. If there is any leaking, check for
loose connections and tighten.

Haier HLP21N Specifications

General

Water consumption per cycle	- L
Energy consumption washing per cycle	- kWh
Dimensions (WxDxH)	447 x 438 x 760 mm
Power requirements	120V, 60Hz
Door hinge	Up
Drum volume	28 L
Loading type	Top-load
Drum material	Stainless steel
Product color	White
Built-in display	No
Appliance placement	Freestanding
Drum capacity	- kg
Spin-drying class	-
Maximum spin speed	700 RPM
Number of washing programs	3
Package weight	51800 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	438 mm
Width	447 mm
Height	760 mm
Weight	43000 g
