1. Press ME and button until the following menu appears on the
screen
ADJUST
AUTO SYNC.
PHASE
CLOCK
H. POSITION
V. POSITION
Note: This menu only appears in PC mode .
2. Press button to enter the adjust menu and to go up and down to
select the desired option
3.Press button to increase and decrease the level to adjust the
selected option to your preference ..
4. Repeat step 2 and step 3 until desired quality has been achieved .
Fun ct ion s:
AUTO SYNC : Is opted for adjustment of picture location frequency and phase
parameters .
50
50
50
50
PHASE : Removes any horizontal distortion and clears or sharpness the displayed
charact ers .
CLOCK : Adjust the TFT-LCD to match the PC input source
H.POSITION : Picture horizontal adjust
V.POSITION : Picture vertical position adjust .
17
