FM-2027
FM-2027
3. CHECKING PROCEDURE
When there is the possibility that a failure has occurred in the sensor or
heater (including the sensor circuit), is displayed and the power is
shut down.
CAUTION
The sensor error also occurs if the tip is not inserted properly.
If the sensor temperature falls below the difference between the current
temperature setting and the low-temperature alarm tolerance, is
displayed and the warning buzzer sounds. When the tip temperature
rises to a value within the set tolerance, the buzzer will stop sounding.
EXAMPLE:
Assume that the temperature setting is 400°C/750°F and the
tolerance 50°C/100°F. If the temperature continues to decrease and
finally falls below the value indicated below while the heating element
is on, the displayed value starts blinking to indicate that the tip
temperature has dropped.
will flash, and the buzzer will sound continuously, when the tip is
inserted wrong way round, an incompatible tip is inserted, or a foreign
object has found its way into the connector.
will be displayed if the connector cord is not attached to the
station OR the wrong soldering iron is connected.
4. ERROR MESSAGES
● Sensor Error
●
Low-temperature alarm tolerance error
●
Heater terminal short-circuit error
● Soldering iron error
350°C (400°C – 50°C)
Set temperature
Set temperature Low-temperature
alarm tolerance
Low-temperature
alarm tolerance
OR
650°F (750°F – 100°F)
EXAMPLE:
