Halyard CO LIEF PMG-Basic - Page 15

15
Displays and Indicators
PARAMETER STATUS DESCRIPTION
Impedance Related
Audio Output
OFF
(Default**)
ON (if enabled)
If enabled in ADVANCED AUDIO SETTINGS, impedance related audio output is generated.
Graph Window
Minimal
The time axis (
) is indenitely scalable during the READY state, accommodating changes to treatment TIME.
The dashed line denoting SET TEMP/TEMP LIMIT/WARNING TEMP will move according to changes made to the SET
TEMP/TEMP LIMIT/WARNING TEMP value.
TRANSDISCAL AND COOLED RF TREATMENT - Pump Status is displayed at the top of the Graph Window.
STIMULATION
READY display
Indicates the system is ready to generate stimulus pulses.
Measurement Window
Impedance
Displayed
Impedance measurements are displayed for all attached thermocouples.
In Multi-RF and Multi-Cooled RF modes, the displayed value is updated every second for each attached
thermocouple.
Status Window None
N/A
** Impedance Related Audio Output can be disabled in the AUDIO SETTINGS, accessible from the ADVANCED SETTINGS mode.
STATE
PARAMETER
Measurement Window Available States Available Settings
Status Description Status Description Status Description
VOLTAGE
STIMULATION
CURRENT
STIMULATION
ON
Impedance
measurements
are displayed.
VOLTAGE
STIMULATION
CURRENT
STIMULATION
AUTO TEMP
MANUAL
POWER
AUTO
PULSED
MANUAL
PULSED
SAVE
SETTINGS
While in the READY
state, other operating
modes for HALYARD*
Pain Management
Thermocouple probes
are available. When a
dierent mode is selected,
the Generator will enter
the READY state of the
new mode.
The present SETTINGS can
be saved as defaults by
holding down the SAVE
SETTINGS key.
VOLTAGE/CURRENT
STIMULATION – The
setting is saved to the
ADVANCED STIMULATION
SETTINGS State, in the
MOTOR and SENSORY
toggle elds.
SELECT PROBE
(Multi-RF)
Available Values A, B, C or D
STIM RATE
Range 1-Shot – 200 Hz
Available Values
†
1-Shot, 2, 5, 10, 20, 50, 75, 100, 150,
180 and 200 Hz
Default**
2 Hz -OR- as set in ADVANCED
STIMULATION SETTINGS State MOTOR
PULSE DUR
Range 0.1–1.0 ms
Available Values
†
0.1, 0.2, 0.5 and 1.0 ms
Default** 1.0 ms
VOLTAGE /
CURRENT
Range
0.00 – 10.0 V/mA (Only adjustable
when STIM RATE is 1-Shot)
Increment 0.01 V/mA
Default**
0.00 V/mA (cannot be overwritten when
the SAVE SETTINGS function is used)
PRESETS
Toggle between MOTOR and SENSORY as specied in the
STIMULATION SETTINGS state, accessible from the ADVANCED
SETTINGS mode. Selecting a Preset modies the STIM RATE.
** Defaults are factory-set, and are overwritten when the SAVE SETTINGS function is used.
†
Time Range set by user does not include factory-set PRE-TREATMENT COOLING Time (45 seconds) or POST-TREATMENT COOLING Time (10 seconds).
