Halyard CO LIEF PMG-Basic - Page 16

16
STATE
PARAMETER
Measurement Window Available States Available Settings
Status Description Status Description Status Description
AUTO TEMP
LESION
ON
Temperature
and Impedance
measurements are
displayed while Time
and Power are not
displayed (dashed
lines replace values).
VOLTAGE
STIMULATION
CURRENT
STIMULATION
AUTO TEMP
MANUAL
POWER
AUTO PULSED
MANUAL
PULSED
SAVE
SETTINGS
While in the READY state,
other operating modes for
HALYARD* Pain Management
Thermocouple probes are
available. When a dierent
mode is selected, the Generator
will enter the READY state of
the new mode.
The present SETTINGS can be
saved as defaults by holding
down the SAVE SETTINGS key.
Multi-Cooled RF only supports
AUTO TEMP LESION mode.
SET TEMP
Range 38° – 95°C
Increment 1°C
Default** 80°C
TIME
Range 15 – 600 s
Increment 1 s
Default** 75 s
MANUAL
POWER
LESION
TEMP
LIMIT
Range 38° – 95°C
Increment 1°C
Default** 80°C
TIME
Range 15 – 600 s
Increment 1 s
Default** 75 s
POWER
LIMIT
Range 0 – 50 W
Increment N/A
Default 0 W
(Cannot be overwritten by SAVE SETTINGS function)
AUTO
PULSED
LESION
SET TEMP
Range 38° – 95°C
Increment 1°C
Default** 42°C
TIME
Range 10 – 900 s
Increment 1 s
Default** 120 s
PULSE
DUR
Range 10 –100 ms
Increment 10 ms
Default** 20 ms
PULSE
RATE
Range 1 –10 Hz
Increment 1 Hz
Default** 2 Hz
MANUAL
PULSED
LESION
WARNING
TEMP
Range 38° – 95°C
Increment 1°C
Default** 42°C
TIME
Range 10 – 900 s
Increment 1 s
Default** 120 s
PULSE
DUR
Range 10 –100 ms
Increment 10 ms
Default** 20 ms
PULSE
RATE
Range 1 – 10 Hz
Increment 1 Hz
Default** 2 Hz
Note: Multi-RF Manual Power and Manual Pulsed modes support 1 probe connected to the Multi-RF module.
** Defaults are factory-set, and are overwritten when the SAVE SETTINGS function is used.
