To Next Page

To Previous Page

Only the End segment is

transmitted

Only the center segment is

transmitted

Modify the length of the Start section M

The length of the Start section can be modified by scanning the "Intercepting length before modification"

M and setting the length of the Start section. The maximum length of the Start section is 255 characters. The

length of the front section M is represented by a hexadecimal character, and the length M is ten Refer to

Appendix D for hex value conversion table.

Modify the length of the Start section M

Modify the length of End section N

Scan the "modified interception length N", and set the scan data setting code, you can modify the length

of the End section, End section allows up to 255 characters, the interception length N using a hexadecimal

character, the length N corresponding to ten Refer to Appendix D for hex value conversion table.

Modify the length of End section N

Only the Start segment is transmitted

Example: When the decoding information is "1234567890123ABC", the first 13 bytes "1234567890123"

1. Check the character table to get the decimal data "13" corresponds to the hexadecimal character "0D"

2. Check whether the setting code is on. If it is not on, please scan the setting code "on" (see section 1.5.2)

3. Scan the "Pre-modification length M" setting code

4. Scan the data setting code "0", "D"

5. Scan "Save" setting code

6. Scan the "Start only transfer" setting code

Only the End segment is transmitted

Example: When the decoding information is "1234567890123ABC", the last three bytes "ABC"

1. Check the character table to get the decimal data "3" corresponds to the hexadecimal character "03"

2. Check whether the setting code is on. If it is not on, please scan the setting code "on" (see section 1.5.2)

3. Scan "Modified cut length N" setting code

4. Scan data setting code "0", "3"

5. Scan "Save" setting code

6. Scan "End segment only" setting code

Hamlet HBCS2D100US User Manual
