Planer-Thicknesser
A3-26 / A3-31 / A3-41
5.4.2 Bridge guard
The bridge guard covers the cutterblock when surface
planing.
! Setscrew (Height adjustment)
" Bridge guard arm
# Protective rail
$ Clamping screw (Width adjustment)
Note: Instructions to adjust the bridge guard are given in the respective working techniques descriptions.
Fig. 5-11: Bridge guard
5.4.1 Safety break switches
The cutter block will only run when the safety switch is
deactivated by the planer tables or extraction hood.
! Break switch for the planer tables
Fig. 5-10: Safety break switches
