Hammer N2-38 - Operation and Storage Conditions; Electrical Connection;Drive Motor

15
Bandsaw
N2-38 / N3800 / N4400
Electrical connection
mains voltage according to specification plate ±10%
Safeguarding see circuit plan
Power supply cord (H07RN-F) 3G1,5 mm²/ 4Gx1,5 mm²
Triggering characteristic C
Drive motor N2-38 Alternating-current motor Three-phase current motor
Motor voltage 1x 230 V 3x 400 V
motor frequency 50 Hz 50 Hz
System of protection IP 54 IP 54
Motor power S6-40 %
*
)
1,5 kW 1,5 kW
Drive motor N 3800 Alternating-current motor Three-phase current motor
Motor voltage 1x 230 V 3x 400 V
motor frequency 50/60 Hz 50/60 Hz
System of protection IP 54 IP 54
Motor power S6-40 %
*
)
1,5 kW 1,5 kW
Drive motor N 4400 Alternating-current motor Three-phase current motor
Motor voltage 1x 230 V 3x 400 V
motor frequency 50/60 Hz 50/60 Hz
System of protection IP 54 IP 54
Motor power S6-40 %
*
)
2,5 kW 2,5 kW
*) S6 = operation under load and intermittent service; 40% = relative operating factor
4.4 Electrical connection/Drive motor
The actual values can be found on the data plate.
4.3 Operation and storage conditions
Specifications
Operating/room temperature +10 to +40 °C
Storage temperature –10 to +50 °C
