33
!
#
$
"
Bandsaw
N2-38 / N3800 / N4400
Safety break switches - hinged lid
1. Prepare the machine to operate.
2. Switch the machine off and ensure that it cannot be
switched on again.
3. Open wheel door
(Lock wheel - Wheel door)
4. Check efficiency:
The machine won´t turn on, the glue pot must be lu-
bricated. (Flap is open)
The machine only runs when the end switch in the in-
side of the machine frame is engaged by the locking
device (Flap is closed)
Fig. 8-4: Safety break switches
!hinged lid (Wheel door)
"Lock wheel
#Safety break switches
$Lock system
Note: The machine only runs when the end switch in the inside of the machine frame is engaged by the
locking device: sliding cover or Flap is closed
Please contact the FELDER KG service department, if problems or a fault- function should occur!
8.6 Safety devices - Check efficiency
