93
Setting the Parameters
5. LEVEL
This is for setting the volume of this wheel.
The setting range is -20 to 0dB. As you increase the value, the volume increases.
6. LEAKAGE WHEEL NUMBER
On this organ, you can produce the sound of each wheel: 61:6C to 91:8F# on the “funda-
mental” wheel: 01:1C to 60:5B; as Leakage Noise at each volume. (See the right figure.)
Select the wheels to output as leakage noise together with the fundamental sound wheel
appearing on the left side of the display.
To select the Leakage Wheel Number, select it by the [VALUE] button or by slightly
moving the feet of the drawbar holding down the key you want to adjust.
7. LEAKAGE WHEEL LEVEL
This is for adjusting the volume of the selected leakage wheel.
Setting range is 0 to 127. However, depending on the situation, the volume may not rise
higher than a certain level, when increasing the value.
NOTE: These parameters are the Tonewheel parameter. If you do the recording operation of the
next page, it works commonly to the same Tonewheel Set (in this example, “BType1”) of
each Combination Preset.
NOTE: When you operate these parameters, if you do not do the recording operation of the next
page, it is lost when you turn off the power.
Concept of the level adjustment
Concept of the leakage noise
To Next Page
