SYSTEM PARAMETERS
Category Parameter SysEx Address SysEx
Length
Data Range Description
MSB to LSB
MIDI
MIDI IN Lower/Other
70 00 00 01
Sequence, Lower, Upper
Local Control
70 00 01 01
O/On
TRx. NRPN (P. <?>)
-- -- -- --
O/On
Tx. Leslie Param.
70 00 02 01
XK/21
Rx. Dump
70 00 03 01
O/On
TRx. Prog. Change
70 00 04 01
O/On
TRx. Drawbar Regi.
70 00 05 01
O/On
Tx. Ext. Zone
70 00 06 01
O/On
Tx. Ext. Zone Program
70 00 07 01
O/On
Tx. Ext. Zone Control
70 00 08 01
O/On
Tx. Multi Contact
70 00 09 01
O/On
Tx. Channel Upper
70 00 0A 01
1 - 16, O
Tx. Channel Lower
70 00 0B 01
1 - 16, O
Tx. Channel Pedal
70 00 0C 01
1 - 16, O
Rx. Multi Contact
70 00 0D 01
O/On
Rx. Channel Upper
70 00 0E 01
1 - 16, O
Rx. Channel Lower
70 00 0F 01
1 - 16, O
Rx. Channel Pedal
70 00 10 01
1 - 16, O
Device ID
-- -- -- --
1 - 32
Assignable
Drawbars
Control Zone
72 00 0g 01
00 - 05
(Ext. U1 to P1)
g: Footage
(0 = 16’, 1 = 5 1/3’... 8 = 1’)
Control Change
72 01 0g 01
0 - 59
(CC#1 - 31, 65 - 95)
Power
Auto O
71 00 00 01
Disable, 30 min
Ext. Leslie
Channel(s)
71 00 01 01
1, 3
