HA<O>
XK-5
Owner’s Playing Guide
154
MIDI TEMPLATE
MIDI TEMPLATE
Template Basic 2or3 KBD SeqMContact
Messages MIDI IN
Sequence Lower Sequence
Local Control
On On On
NRPN
On On On
Program Change
On On On
Drawbar Registration
On On On
External Zone
O O O
Transmit Channel Tx. Upper
1 1 1(disregarded)
Tx. Lower
2 2 4(disregarded)
Tx. Pedal
3 3 7(disregarded)
Tx. Multi
O O On
Rx. Upper
1 1(disregarded) 1(disregarded)
Rx. Lower
2 2 (disregarded) 4(disregarded)
Rx. Pedal
3 3 (disregarded) 7(disregarded)
Rx. Multi
O O On
Comments
is template is used for re-
cording / playing back a perfor-
mance to / from an external se-
quencer either stand-alone or
with a Pedal Clavier.
is template is used for play-
ing the XK-5 with a Lower
Manual connected to the
MIDI IN OTHER jack, and a
Pedal Clavier connected to the
MIDI IN PEDAL jack.
is template is used for re-
cording / playing back a perfor-
mance to / from an external se-
quencer with XLK-5 /
XPK-250 and multi-contact
signal.
e MIDI channels are set
from 1 to 9.
Template Use Ex. Zone Use Ex. 2or3KB
Messages MIDI IN
Sequence Lower
Local Control
On On
NRPN
On On
Program Change
On On
Drawbar Registration
On On
External Zone
On On
Transmit Channel Tx. Upper
O O
Tx. Lower
O O
Tx. Pedal
O O
Tx. Multi
O O
Rx. Upper
1 1 (disregarded)
Rx. Lower
2 2 (disregarded)
Rx. Pedal
3 3 (disregarded)
Rx. Multi
O O
Comments
is template is used for con-
trolling MIDI equipment via
External Zones when playing
either stand-alone or with a
Pedal Clavier.
is template is used for con-
trolling MIDI equipment via
External Zones when playing
using a Lower Manual and a
Pedal Clavier connected to the
MIDI IN jack.
