XK-5
Owner’s Playing Guide
168
Drawbar Keyboard
MIDI Implementation Chart
Date: 27-Nov-2014
Model: XK-5
Version: 1.0
Function Transmitted Recognized Remarks
Basic
Channel
Default
*1 *1 *1: Upper = 1, Lower = 2,
Pedal = 3
Changed
1 - 16 1 - 16
Mode
Default
3 3
Messages
X X
Altered
***** X
Note
Number
12 - 120 36 - 96
: True Voice
***** 36 - 96
Velocity
Note ON
O O
Note OFF
X X
After Touch
Key’s
X X
Ch’s
X X
Pitch Bend
X X
Control
Change
0, 32
O O Bank Select MSB, LSB
1
X X Modulation
6, 38
O O Data Entry MSB, LSB
7
O O Volume
10
O X Pan
11
O O Expression
12 - 20, 80
O O Drawbar Reg. Upper
21 - 29, 81
O O Drawbar Reg. Lower
33, 35, 82
O O Drawbar Reg. Pedal
48
O O Spring Shock
49
O O Glide
64
O O Damper
69
O O Sustain
92
X O Leslie Fast
98, 99
O O NRPN MSB, LSB
Program
Change
O O
: True #
0 - 127 0 - 99, 126, 127
Patches, Adjust A
<
, B
System Exclusive
O O
System
Common
: Song Position
X X
: Song Select
X X
: Tune
X X
System
Real Time
: Clock
X X
: Commands
X X
Aux
Messages
: All Sounds O
X O (120)
: Reset All Controllers
O O (121)
: Local On/O
X X
: All Notes O
O O
: Active Sense
O O
: Reset
X X
Mode 1: OMNI ON, POLY Mode 2: OMNI ON, MONO
Mode 3: OMNI OFF, POLY Mode 4: OMNI OFF, MONO
O: Yes
X: No
MIDI IMPLEMENTATION CHART
