Owner’s Playing Guide
90
CUST. TW Edit Menu
is Edit Menu allows you to select from among a library of dierent Tone Wheel settings as well as create your own Custom Tone Wheels.
❶ ORGAN TYPE
is allows you to select the organ type to edit: “A-100,” “B-3,” “C-3” and “Mellow.”
❷ CUSTOM NUMBER (P)
is allows you to select the “CUSTOM NUMBER” to use or compile. e setting range is
F1 to F3 (not re-writable) and U1 to U3 (re-writable). See right tree for detail.
e symbol “*” will be displayed when the virtual Tone Wheel parameters are edited (shown
below
❸ to ❼).
NOTE: This parameter is a Patch Parameter and is recorded as part of a Patch.
u CUSTOM TONE WHEEL PARAMETERS
NOTE: None of these parameter settings will be remembered unless they are saved as a
Custom Tone Wheel.
❸ CUSTOM NAME (TW)
is allows you to enter name the Custom Tone Wheels set using up to 10 letters.
Use the [][] Touch Buttons to move the cursor, then use the [VALUE] Rotary Knob to
select characters.
NOTE: See page 93 for detailed instructions on naming Custom Tone Wheels.
❹ WHEEL NUMBER (TW)
is allows you to select the number of the Tone Wheel you want to regulate.
e setting range is displayed by “wheel# : note” style,
01: 0C to 12: 0B,
F01: 0C to F12: 0B,
13: 1C to 91: 8F# and
F92: 8G to F96: 8B.
“F” means the wheel used for extended fold-back. e non-marked Wheel Number means
original wheel from B-3/C-3.
To select the Wheel Number, select the [VALUE] Rotary Knob here, or slightly move the
footage of the Drawbar while depressing the key you want to regulate (see the illustration
on the right).
When the Wheel Number is selected, each parameter for the wheel (
❺, ❻, ❼) is updated.
NOTE: Set the [TRANSPOSE] and [OCTAVE] at “0” to select a correct wheel.
MENU/EXIT
ENTER
A-100
B-3
C-3
F1
F2
F3
U1
U2
U3
F1
F2
F3
U1
U2
U3
F1
F2
F3
U1
U2
U3
Mellow
F1
F2
F3
U1
U2
U3
Custom Tone Wheels
To locate this Menu, follow the steps below:
❶
❷
❸
❹ ❺ ❻
❼
UPPER
BANK KEY PAT CH
PEDAL LOWER
How to select the WHEEL NUMBER to edit
