Hammond XPK-100 User Manual

35
Specifications
Hammond XPK-100 Quick Features Guide
SPECIFICATIONS
! 13-note pedalboard, fixed velocity
! LED display: 7 segments, 3 characters
! Panel Switches: PLAY/EDIT, PRESET/EDIT Plus and Minus, TRANSPOSE/LOCK, CONTROL
! Jacks, DC power input, MIDI IN 1, MIDI IN 2, MIDI OUT
! Accessories, AC power supply, MIDI cable
! Weight: 8.5 kg
! Dimensions: W 56cm D 39cm H 13cm
Ë Appendix A - EDIT Parameter List
Advanced Feature Values
*E00 PK MIDI Channel 1 ~ 16
*E01 Transpose -5 ~ +6
*E02 Octave -1 ~ +4
*E03 Poly/Mono Mode Poly/Mono
*E04 PK Hold ON/OFF ON/OFF
*E05 PK Volume 1 ~ 127
*E06 Fixed Vel. Value 1 ~ 127
*E07 Control Channel 1 ~ 16, Pedal
*E08 CONTROL Sw. Func. See page 23
*E09 CONTROL Sw. Mode Alternate/Momentary
*E10 Program Change OFF, 1 ~ 128
*E11 Bank Select MSB 0 ~ 127
*E12 Bank Select LSB 0 ~ 127
E13 System Preset Reset, MIDI Merge ON/OFF, MIDI Data
Dump
* - Data can be saved to a Preset.
Ë Appendix B - Default Preset Settings
Advanced Feature Default Setting
E00 PK MIDI Channel 3
E01 Transpose 0
E02 Octave 0
E03 Poly/Mono Mode Mono
E04 PK Hold ON/OFF OFF
E05 PK Volume 127
E06 Fixed Vel. Value 100
E07 Control Channel 1
E08 CONTROL Sw. Func. Pedal Sustain LONG
E09 CONTROL Sw. Mode Alterna te
E10 Program Change Same as Preset Number
E11 Bank Select MSB 0
E12 Bank Select LSB 0
E13 System Reset

Hammond XPK-100 Specifications

General

Brand	Hammond
Model	XPK-100
Category	Music Pedal
Language	English
