Hammond XPK-100 User Manual

14
Advanced Features
Hammond XPK-100 Quick Features Guide
Current Parameter Current Value
Current Parameter Current Value
Ë Advanced Feature - E02 Octave
This Advanced Feature allows you to select the Octave in which the XPK-100 will sound. You can select
from “-1" (down 1 octave) through “4” (up 4 octaves). The default setting is “0.”
NOTE: The OCTAVE LED to the right of the Information Center Display will light whenever the XPK-100 is set to play in any
octave other than “0.”
TRY THIS:
1. From PLAY Mode, press the PLAY/EDIT Switch once. The Information Center Display
should alternate between two messages as shown below:
2. Press the PRESET/EDIT “” Switch repeatedly until the Information Center Display
alternates between two messages as shown below:
NOTE: You can also press the PRESET/EDIT “” Switch to arrive at the same Advanced Feature selection.
3. Now use the Pedal keys to select the MIDI Channel you want.
Using the DEC/INC Pedal keys:
Use the DEC (“A<”) Pedal key to decrease the Octave number selection.
Use the INC (“B”) Pedal key to increase the Octave number selection.
Using the other Pedal keys:
You can use the other Pedal keys to select Octaves. The data chart below shows how to do this.
OCTAVE SELECTIONS
Octave Selection Action
Unison Press the “Lo C” Pedal
Up 1 octave Press the “C<” Pedal
Up 2 octaves Press the “D” Pedal
Up 3 octaves Press the “D<” Pedal
Up 4 octaves Press the “E” Pedal
NOTE: Pressing the “F” through the “B” Pedals will have no effect.
