Hamtronix ELEKTRA 2500 User Manual

ELEKTRA 2500 HAMTRONIX
9
07 - ROLLER BEEP (Default = 0)
Determine after how many key ups the type of courtesy tone will automatically change.
0 Disable
2 every 10
4 every 40
6 every 80
1 Each transmission
3 every 20
5 every 60
7 every 100
Note: Options 0 and 1 should only be used for demo purposes, since the constant change of courtesy tones can
cause some users to key up all the time and bother other listeners. If function 06 is used, Roller Beep will be disabled.
08 – CONFIRMATION TONE (Default = 1)
Determine the type of confirmation sound.
0 No confirmation sound
1 Two high frequency tones
2 Melody
09 – TIME-OUT ACTION (Default=1)
When time-out is exceeded, you can choose between transmitter drop until the signal that caused the drop
disappears or just a funeral march sound of warning.
0 Timer-out warning sound
1 Transmitter drop
Note: If the transmitter drops and the signal that caused the drop is still blocking the repeater, if you have a stronger
signal you can press * to bring the transmitter back.
10 – ID TEST
This function will allow you to test the IDs and check the controller’s version and serial number.
1 Voice Message 1 playback
2 Voice Message 2 playback
3 CW ID
4 Software version
11 – REPEATER CTCSS ENABLE (Default = 0)
When enabled, will require a correct CTCSS to operate the repeater port.
0 Disable
1 Enable
Note: This function should only be activated if there is a CTCSS decoder installed. It can be built-in, as in Elektra
2500CT model, external such as the Hamtronix TED300 module or from inside of the receiver. TONE1 input (CN1-
6) is active with logic level 0 (voltage less than 0.6V) when the correct PL/CTCSS is present. Level 1 (greater than
3V and less than 5.5V) indicates absence of PL/CTCSS.
12 – AUXILIARY CTCSS ENABLE (Default = 0)
When enabled, will require a correct CTCSS to operate the auxiliary port.
0 Disable
1 Enable
Note: This function should only be activated if there is a CTCSS decoder installed. It can be external such as the
Hamtronix TED300 module or from inside of the receiver. TONE1 input (CN2-6) is active with logic level 0 (voltage
less than 0.6V) when the correct PL/CTCSS is present. Level 1 (greater than 3V and less than 5.5V) indicates absence
of PL/CTCSS.
13 – PL/CTCSS FREQUENCY SELECTION (Default=0)
Sets the frequency of the build in PL/CTCSS decoder of the Elektra 2500CT model.
CTCSS
Option
CTCSS
Option
CTCSS
Option
CTCSS
Option
CTCSS
Option
CTCSS
Option
-
00
85.4
08
110.9
16
146.2
24
183.5
32
210.7
40
67.0
01
88.5
09
114.8
17
151.4
25
186.2
33
218.1
41
69.3
02
91.5
10
118.8
18
156.7
26
189.9
34
225.7
42
71.9
03
94.8
11
123.0
19
159.8
27
192.8
35
229.1
43
74.4
04
97.4
12
127.3
20
162.2
28
196.6
36
233.6
44
77.0
05
100.0
13
131.8
21
167.9
29
199.5
37
241.8
45
79.7
06
103.5
14
136.5
22
173.8
30
203.5
38
250.3
46
82.5
07
107.2
15
141.3
23
179.9
31
206.5
39
254.1
47
Example: To select PL/CTCSS 74.4Hz enter: 123413#04#
