Technical specifications
41
8 Technical specifications
8.1 Product specifications
Manufacturer: Handicare
8.1.1 Calypso
Technical specification according to ISO 7176-15
Calypso 3-wheel version
Model
Calypso 4-wheel version
Maximum user's weight 125 kg
Description Min. Max.
Total length 1180 mm
Total width 620 mm
Total weight incl. batteries 78 – 86 kg
1
82 -90 kg
1
Transport weight heaviest part 22 kg
Static stability downward 9°
Static stability upward 9°
Static stability sideways 9°
Energy consumption: theoretic maximum
distance
38 km
2
Dynamic stability on slopes 6°
Climbing capacity for obstacles 50 mm
Maximal speed forward 8 km/h
Minimum brake distance from maximum speed 1500 mm
Seat angle 5°
Effective seating depth 440 mm
Effective seating width 440 - 580 mm
Sitting height from the front 460 - 485 - 510 - 535 mm
Back angle 95° - 130°
Back height 400 mm
1. Values given are applicable to the use of a 30 Ah and 40 Ah battery, respectively.
2. Tested according to EN12184 with 40Ah batteries.
Description
Minimum radius 1030 mm 1610 mm
3
Capacity to drive over obstacles 50 mm
Ground clearance 120 mm
Turning space 1585 mm 1780 mm
3
Test data
Weight test dummy 100 kg
