16
Step 16
Remove the servo hatch cover and re-drill the holes
using a 5/64" (2mm) drill bit. Use 2–3 drops of thin
CA to harden the underlying wood. This will prevent
the screws from crushing the wood when they are
tightened. Secure the hatch using four #2 x 3/8" screws.
Step 17
Remove the back plate from a control horn
using side cutters or a sharp hobby knife.
Step 18
Position the control horn on the aileron so the
horn aligns with the aileron servo horn and the
aileron hinge line. Mark the position for the
mounting holes using a felt-tipped pen.
Step 19
Drill three 3/32" (2.5mm) holes at the
locations marked in the previous step.
Section 2: Aileron Installation
