16
Characteristics
Model CDD12-AC1S CDD14-AC1S CDD16-AC1S CDD20-AC1S
Operator type Stand-on Stand-on Stand-on Stand-on
Load capacity Q (kg) 1200 1400 1600 2000
Load center c(mm) 600 600 600 600
Wheelbase y(mm) 1405 1405 1425 1425
Weight
Service weight with battery kg 1310 1315 1362 1405
Wheels﹠Tyres
Tyre type PU PU PU PU
Tyre size/Quantity,operator side mm Φ230×75/1 Φ230×75/1 Φ230×75/1 Φ230×75/1
Tyre size/Quantity,load side mm Φ85×70/4 Φ85×70/4 Φ85×70/4 Φ85×70/4
Auxiliary wheel size/Quantity mm Φ140×55/1 Φ140×55/1 Φ140×55/1 Φ140×55/1
Tread, operator side b10(mm) 525 525 525 525
Tread, load side b11(mm) 385 385 385 385
Dimensions
Lift height h3(mm) 2700 2700 2700 2700
Fork height, lowered h13(mm) 90 90 90 90
Overall length(fold the pedal) L1(mm) 2075
1)
2075
1)
2095
1)
2095
1)
Overall length(unfold the pedal) L1(mm) 2507
1)
2507
1)
2527
1)
2527
1)
Overall width b1(mm) 800 800 800 800
Fork size s/e/L(mm) 65×185×1150 65×185×1150 65×185×1150 65×185×1150
Outside fork width b5(mm) 570/680 570/680 570/680 570/680
Ground clearance, center of wheelbase, min m2(mm) 30 30 30 25
Min, right angle stacking aisle width1000×1200
across forks
Ast(mm) 2513
1)
2513
1)
2533
1)
2533
1)
Min, ringht angle stacking aisle width 800×1200
across forks
Ast(mm)
2482
1)
2482
1)
2502
1)
2502
1)
Outer turning radius, min Wa(mm) 1642 1642 1662 1662
Performance
Travel speed, laden/unladen km/h 7.0/7.0 7.0/7.0 7.0/7.0 7.0/7.0
Lift speed, laden/unladen mm/s 87/133 129/198 108/160 98/160
Lowering speed, laden/unladen mm/s 155/158 213/200 185/155 195/155
Max Gradeability, laden/unladen % 10/16 10/16 8/16 8/16
Motor﹠Battery
Drive motor power kW 2.2 2.2 2.2 2.2
Lift motor power kW 2.2 3.0 3.0 3.0
Steering motor power kW 0.2 0.2 0.2 0.2
Battery voltage, rated capacity V/Ah 24/280 24/280 24/340 24/340
Optional battery voltage, rated capacity V/Ah 24/340 24/340
Controller mode Curtis AC Curtis AC Curtis AC Curtis AC
Note：1）Triplex Mast +21mm.
