HANGCHA CDD12-AC1 - Hydraulic System

89
2 Hydraulic system
Hydraulic system is mainly composed of hydraulic unit, lifting cylinder and rubber tube etc.
1. Hydraulic unit
2. Rubber tube assembly
3. Rubber tube assembly
4. Pipeline assembly
5. Left lifting cylinder
6. Right lifting cylinder
Fig. 2-1 Hydraulic system
1
2
3
4
5
6
