19
Characteristics
Model CTD12-AC1 CTD14-AC1 CTD16-AC1 CTD20-AC1
Operator type Pedestrian Pedestrian Pedestrian Pedestrian
Load capacity Q (kg) 1200 1400 1600 2000
Load center c(mm) 600 600 600 600
Wheelbase y(mm) 1405 1405 1425 1425
Weight
Service weight with battery kg 1247 1252 1285 1328
Wheels﹠Tyres
Tyre type PU PU PU PU
Tyre size/Quantity,operator side mm Φ230×75/1 Φ230×75/1 Φ230×75/1 Φ230×75/1
Tyre size/Quantity,load side mm Φ85×70/4 Φ85×70/4 Φ85×70/4 Φ85×70/4
Auxiliary wheel size/Quantity mm Φ140×55/1 Φ140×55/1 Φ140×55/1 Φ140×55/1
Tread, operator side b10(mm) 525 525 525 525
Tread, load side b11(mm) 1000/1170/1370 1000/1170/1370 1000/1170/1370 1000/1170/1370
Dimensions
Lift height h3(mm) 2700 2700 2700 2700
Fork height, lowered h13(mm) 50 50 50 50
Overall length L1(mm) 1980
1)
1980
1)
2000
1)
2000
1)
Overall width b1(mm) 1100/1270/1470 1100/1270/1470 1100/1270/1470 1100/1270/1470
Fork size s/e/L(mm) 35×100×1070 35×100×1070 35×100×1070 40×122×1070
Outside fork width b5(mm) 210～790 210～790 210～790 210～790
Ground clearance, center of wheelbase, min m2(mm) 40 40 40 40
Min, right angle stacking aisle width1000×1200
across forks
Ast(mm) 2547
1)
2547
1)
2567
1)
2567
1)
Min, ringht angle stacking aisle width 800×1200
across forks
Ast(mm) 2516
1)
2516
1)
2536
1)
2536
1)
Outer turning radius, min Wa(mm) 1643 1643 1663 1663
Performance
Travel speed, laden/unladen km/h 6.0/6.0 6.0/6.0 5.0/6.0 5.0/6.0
Lift speed, laden/unladen mm/s 87/133 129/198 108/160 98/160
Lowering speed, laden/unladen mm/s 155/158 213/200 185/155 195/155
Max Gradeability, laden/unladen % 8/16 8/16 5/16 516
Motor﹠Battery
Drive motor power kW 1.5 1.5 1.5 1.5
Lift motor power kW 2.2 3.0 3.0 3.0
Battery voltage, rated capacity V/Ah 24/240 24/240 24/280 24/280
Optional battery voltage, rated capacity V/Ah 24/340 24/340 24/340 24/340
Controller mode Curtis AC Curtis AC Curtis AC Curtis AC
Note：1）Triplex Mast +21mm.
