4
CPD40/45/50J-D1
Model
Rated
Power
( kw)
Rated
Voltage
(V)
Rated
Current
(A)
Rated
speed
(r/m)
Max.
Speed
(r/m)
Excitations
Mode
Insulation
Grade
Cooling
Mode
Protecting
Grade
Ration
(m)
Weight
(Kg)
Remark
TSP180/4-200
16.6
52
／
/
/
AC
F
IC01
IP20
60
/
tow
TSP160/4-250-T
25
49
387
1620
/
AC
F
IC01
IP20
5
/
work
electromotor
applied range
Height above sea level
No exceed 1200m
Remark
Environment temperature
highest/lowest
40
0
C/-25
0
C
Relative temperature
Until on the surface of motor dew 100%
Cooling air
Must not contain volatile gas
most work
current of the
motor
Tractor motor
Three times of rated current ,admit
time is one minute
Lifting motor、steering motor
One point eight times of rated current
,admit time is one minute
Admit temperature Rolling bearing（Environment
temperature not exceed 40
0
C）
95
0
C
From brush box catadrome side to surface of the
commutation
2～4mm
JD1
not
Cooling insulation resistance（When it approach work
temperature, please measure by 250Vmegohmmeter）
< 45V 0.5MΩ
45V～110V 1MΩ
Brush
Metal plumbagin brush trade J201 chart No 5CZ 、 578
JD1
not
