HANGCHA CPD30J - Engine for Forklift

1
1. Driving system
Drive system is composed most components such as electrical engineering, gear box, driving axle
detent tyre and wheel rim.
Gear box is two grades reduce speed gear, one grade straight gear and one grade planet gear. So the
gear box is very small.
Detent is a hoof detent, if you need know the particular content, you can see relevant portion of the
trig system.
1.1 Engine for Forklift
1.1.1Data
CPD10/15J/18J
Model
Rated
Power
( kw)
Rated
Voltage
(V)
Rated
Current
(A)
Rated
speed
(r/m)
Max.
Speed
(r/m)
Excitations
Mode
Insulation
Grade
Cooling
Mode
Protecting
Grade
Ration
(m)
Weight
(Kg)
Remark
XQ – 5–3A
5.3
45
139
1700
3200
separate
excitation
F
IC01
IP20
60
95
tow
XQD –8.2-3D
8.2
45
172.8
1600
3200
series
excitation
F
IC01
IP20
5
65
work
CPD20/25J
Model
Rated
Power
( kw)
Rated
Voltage
(V)
Rated
Current
(A)
Rated
speed
(r/m)
Max.
Speed
(r/m)
Excitations
Mode
Insulation
Grade
Cooling
Mode
Protecting
Grade
Ration
(m)
Weight
(Kg)
Remark
XQ-7A
7
45
180
1200
2400
separate
excitation
F
IC01
IP20
60
112
tow
XQD-8.6-3D
8.6
45
248
1600
3200
series
excitation
F
IC00
IP44
5
72
work
CPD30J
Model
Rated
Power
( kw)
Rated
Voltage
(V)
Rated
Current
(A)
Rated
speed
(r/m)
Max.
Speed
(r/m)
Excitations
Mode
Insulation
Grade
Cooling
Mode
Protecting
Grade
Ration
(m)
Weight
(Kg)
Remark
XQ – 10.2 A
10.2
75
162.5
1500
/
separate
excitation
F
IC01
IP20
60
120
tow
XQD - 10 -3D
10
75
161.6
2000
/
series
excitation
F
IC01
IP20
15
83
work
