HANGCHA CPD30J - Driving Axle

9
24. Girth gear
25. bolt
26.nut
27.right differential
carrier
28.left differential
carrier
29. Gear shaft (I)
30. Face gear
31. Gasket
32. Planetary gear
33. Thrust washer
34. Axletree 6211
35. Straight pin
36.Gear shaft (II)
37. Paper gasket
38.pin
39. Lock plate
40. Lock washer
1.3 Driving axle
1.3.1 Data
Type
1-1.8t
2-2.5t
3t
4-5t
Driving axle type
Full floating, axle and truck body direct install, front
wheel driving
Tire pressure
10.30MPa
Wheel hub rotation starting torque at hub blot N
10～29
Axial play of wheel bearing mm
less than 0.08
weight
Kg
125-130
195-198
202-208
350-380
1.3.2 Trouble diagnoses and corrections
condition
Probable cause
Corrective action
Abnormal noises
·loose driving axle and body connecting blots.
·loose wheel nut
·worn or damaged wheel hub bearing.
·wheel hub bearing not properly adjusted.
·worn axle shaft spliner.
·insufficient lubrication
Tighten.
Tighten.
Replace.
Adjust.
Replace.
Lubricate.
Unstable driving
·loose wheel nut.
·deformed wheel.
·worn or damaged wheel hub bearing.
·loose driving axle and body connecting blots.
·wheel hub bearing not properly adjusted.
·improper tire pressure.
Tighten.
Replace.
Replace.
Tighten.
Adjust.
Adjust.
Oil leakage
·worn or damaged axle shaft oil seal.
·final drive improperly installed.
·loose drain plug.
Replace
Replace gasket.
Tighten.
