HANGCHA CPD30J - Page 49

43
CODE
PROGRAMMER
LCD DISPLAY
POSSIBLE CAUSE
7，1
OS General
1. Internal controller fault.
7，2
PDO Timeout
1. Time between CAN PDO messages received exceeded the PDO
Timeout Period.
7，3
Stall Detect
1. Stalled motor.
2. Motor encoder failure.
3. Bad crimps or faulty wiring.
4. Problems with power supply for the motor encoder.
5. See 1311 menu Monitor » Motor: Motor RPM.
8，7
Motor
Characterization Fault
1. Motor characterization failed during the motor characterization process.
8，8
Encoder
Characterization Fault
1. Encoder characterization failed during the motor characterization
process.
2. Motor encoder pulse rate is not a standard value (32, 48, 64, 80 ppr).
8，9
Motor Type Fault
1. The Motor type parameter value is out of range.
9，2
EM Brake Failed to
Set
1. Vehicle movement sensed after the EM Brake has been commanded to
set.
2. EM Brake will not hold the motor from rotating.
9，3
Limited Operating
Strategy（LOS）
1. Limited Operating Strategy (LOS) control mode has been activated, as
a result of either an Encoder Fault (Code 36) or a Stall Detect Fault (Code
73).
2. Motor encoder failure.
3. Bad crimps or faulty wiring.
4. Vehicle is stalled.
9，4
Emer Rev Timeout
1. Emergency Reverse was activated and concluded because the EMR
Timeout timer has expired.
2. The emergency reverse input is stuck On.
Lifting (pump) controller error code table is the same as that of CPD10-30J.
CPD10/15/18/20/25/30/35J C2、CPD40/45/50J C2 EC ERROR CODE TABLE
Lifting (pump) controller error code table is the same as that of CPD10-30J C1
Towing controller error code table is the same as that of CPD10-30J C1
