46
6.3.2 Error code
(1) Errors detected by VMC20
Code.
Source
Condition
When
Tract
Main
PS
Reset
Remark
101
Switch startup error
ACCEL switch active at startup
KEY→ON
OFF
ON
-
ACC SWITCH=OFF
Traction setspeed=0
102
Switch startup error
FW|REV switch active at startup
KEY→ON
OFF
ON
FW=REV= OFF
Traction setspeed=0
103
Direction switch
error
FW and REV ON at the same time
KEY=ON
OFF
ON
-
KEY=OFF
Traction setspeed=0
104
Accel pot error
Pot voltage > 95% or Pot voltage <
5% of VX_out
KEY=ON
ON
ON
-
KEY=OFF
Traction setspeed=0
105
Accel switch error
Voltage > 30% when ACC switch
is not active
KEY=ON
ON
ON
-
KEY=OFF
Traction setspeed=0
107
Battery under
voltage
48V:Less than 28.2V/.8s
36V: Less than 24.8V/.8s
KEY=ON
OFF
OFF
-
KEY=OFF
Detected by VMC20, not by ACS.
108
ACS under voltage
Voltage < limit (Parameter) for
more than 0.8sec
KEY=ON
OFF
OFF
-
KEY=OFF
Detected by VMC20, not by ACS
109
Battery over voltage
More than 65V/0.8s
KEY=ON
OFF
OFF
-
KEY=OFF
Detected by VMC20, not by ACS.
110
ACS over voltage
Voltage > limit (Parameter) for
more than 0.8sec
KEY=ON
OFF
OFF
-
KEY=OFF
Detected by VMC20, not by ACS
111
Communication
error
See 5.2.1.
KEY=ON
OFF
ON
-
KEY=OFF
Traction setspeed=0
112
PM brush wear
wear and tearsensor = ON
KEY=ON
-
KEY=OFF
Only happens at the place where the
option sensor install.
113
PM thermal
PMheat sensor = ON
KEY=ON
-
ON
-
KEY=OFF
Only happens at the place where the
option sensor install.
114
Battery low voltage
batteryLED = ON
KEY=ON
OFF
ON
-
Charge a battery.
115
Startup error
Startup interior error
KEY=ON
OFF
ON
KEY=OFF
Connect with the engineer of Danaher
