ENGINEERING DATA
SPECIFICATIONS
MODEL
Rated Capacity
1
(scfm)
Inlet /Outlet
Connections
Dimensions - inches (mm)
Net Weight
lbs (kg)
Height Width Length
FLX 1.1
75 NPT 1”
29.6
(751)
14.3
(363)
23.7
(603)
120
(54.5)
FLX 1.2
100 NPT 1”
28.0
(711)
14.3
(363)
30.7
(781)
147
(66.5)
FLX 1.5-1
150 NPT 2”
30.0
(761)
17.4
(443)
35.5
(901)
203
(92)
FLX 1.5
150 NPT 2”
30.0
(761)
17.4
(443)
35.5
(901)
189
(85.5)
FLX 2.1
200 NPT 2”
30.0
(761)
17.4
(443)
37.8
(961)
217
(98.5)
FLX 2.1-4
200 NPT 2”
30.0
(761)
17.4
(443)
37.8
(961)
244
(110.5)
FLX 3.1
300 NPT 2”
35.9
(911)
19.4
(493)
43.7
(1,111)
324
(147)
FLX 4.1
400 NPT 2”
35.9
(911)
19.4
(493)
43.7
(1,111)
335
(152)
FLX 4.5
450 NPT 2”
40.6
(1,032)
19.5
(494)
49.3
(1,253)
366
(166)
FLX 5.5
550 NPT 2”
40.6
(1,032)
19.5
(494)
49.3
(1,253)
396
(180)
1
Rated Flow Capacity - Conditions for rating dryers are in accordance with ISO 7183 (Option A2).
Compressed air at dryer inlet: 100 psig (6.9 barg) and 100°F (38°C); ambient air temperature: 100°F (38°C), operating on 60 Hz power
supply.
2
Refer to dryer data plate for refrigerant charge.
ELECTRICAL DATA
MODEL
Power Supply
Power
Consumption
(kW)
Refrigerant
Voltage Phase Hz
FLX 1.1
115 1 60 0.54
R-134a
FLX 1.2
115 1 60 0.62
FLX 1.5-1
115 1 60 1.04
R-407c
FLX 1.5
230 1 60 0.85
FLX 2.1
230 1 60 1.32
FLX 2.1-4
460 3 60 1.26 R-134a
FLX 3.1
460 3 60 1.99
R-407c
FLX 4.1
230 1 60 2.54
FLX 4.5
460 3 60 3.23
FLX 5.5
460 3 60 3.42
