HANKISON SPXFLOW HSHD-21 User Manual

27
11.9 Electrical Schematic With Electronic Drain Option
1 2 3 4 5
6 7
8 9
A B C D E
F
G H
0
5
L / X101
PE N
L
L N PE V+ V–
N / X100
PE / X102/ X103
A11
T11
+VIN
GND
X200
+24V
VENT1
X503
+24V
VENT2
X504
Analog
24V
X100
REM
GND
ERR
GND
A14
X500
X501
X502
DRY SERVICE
ERROR
X100
120V ±10% / 50-60Hz / 0.7A
X1.2
X1.1
A17
Y15
Y16
NC
X2.3
CO X2.2
RJ45
F
I
+ -
3+
1-
24VDC / 1.5A
100-240VAC/50-60Hz/0.74A
24VDC/1.5A
B61
50Vdc, 0.5A 50VAC, 1A
left
purge valve
right
purge valve
Dryer
Operation
Service
Warning
Fault
DTP
Sensor
Remote
O (Customer)
Feed terminal strip
Control
Power supply board
Contact Rating
Drain
Fault
OPTION
OPTION
